Product Parameters:

• Laser Source: 20W/30W/50W JPT LP-E
• Adjustable Frequency Range: 1-600kHz
• Pulse Width: 200ns
• Marking Speed:≤7m/s(275.6in/s)
• Output Power Adjustment Range: 10%-100%
• Electrical Requirements: 110V-240V/50Hz-60Hz
• Power Consumption: 500W/800W/1000W
• Rotary Axis: D69/D80/D100/D125mm Optional
• Software: EZCAD2 (Lightburn Compatible) / EZCAD3
• Communication Mode for Automation: TCP/IP, IO, RS232
• Marking Content: Barcodes, Serial Numbers, Text, Vector, Logos
• Marking Interface: USB Connection. Compatible with Windows XP/Vista/7/8/10/11
• Re-position Precision: 0.002mm; High-Rate of Electrical-Optical Conversion: 70%
• Minimum Line Width 0.01mm(0.004in); Minimum Character 0.02mm(0.008in)
• Engraving Depth: 20W≤0.2mm(0.008in)/ 30W≤0.4mm(0.016in)/ 50W≤1mm(0.039in)
• Marking Area(Lens): 110*110mm(4.3*4.3in)/150*150mm(5.9*5.9in)/175*175mm(6.9*6.9in)
• Maximum Material Thickness: 110*110mm:300mm(11.8in)/150*150mm:250mm(9.8in)/175*175mm:206mm(8.1in)

Features and Advantages:

• Infrared Distance Sensor. Automatically Calculate the Focal Length to Achieve Precise Focus.
• Auto Focus System. Comes with Auto, UP & Down Button for Easy Focusing.
• Sino-Galvo AF2206S-600 Galvometer. Auto focus, good running stability, high positioning accuracy, high marking speed, strong anti-interference ability.
• Compatible with Multiple File Formats: Coredraw, AutoCAD, Photoshop; PLT, PCX, DXF, BMP, etc Supported. Directly use SHX, TTF Fonts.
• Automatic Encoding, Printing Serial Number, Batch Number, Date, Barcode, QR Code, Automatic Jump Number, etc Supported.
• Double Red Dot Focusing: Red Guideline and Red Dot for Easy Focusing.
• Red Dot Pointer: Since the laser beam is invisible, the red dot pointer allows you to have a visual reference for locating where the laser will fire.
• High Quality Machine Parts: JPT LP-E Laser Source,  Jollystar & OPEX F-Thea Lens,  Sino-Galvo AF2206S-600.
• Easy Operation, English User Manual, VCD Training Video, Software Sending Together with the Machine. ISO, CE & FDA Certificate.

Application and Service:

• Applicable Materials: Aluminum, Stainless Steel, Brass, Copper, etc. Also Some of Nonmetal Such as Nylon, Light Button, ABS, PVC, PES, etc.
• Applicable Industry: Hardware Industry, Wrenches, Measuring Tools, Sanitary Ware, Stainless Steel, Medical Equipment, Luggage, Gifts, Table Bottom, Glasses Frames, Instruments.
• US Stock No Import Duty+Free shipping by DHL/UPS around 5 to 7 days to your Door.
• 2 Years Warranty. After Sales Center in NY, US. Offer Remote Assistance for Operation Issues. Offer Lifetime Online Technical Support.
• We also have  JPT Fiber Laser Engraver without Auto Focus Function for Optional.
