Technical Parameters:

• Laser Source Power: JPT 2000W
• Scanning Width: 160±10mm
• Laser Type: Continuous
• Output Power: 10KW(Chiller included)
• Cleaning Efficiency: 15-45m2/h
• Cable Length: 10m
• Laser wavelength: 1080±10nm
• Voltage:380V 3-Phase，50/60Hz (Transformer provided)
• Environment Humidity: ≤70% without condensation
• Cooling Method: Water cooling
• Cooling Water Requirements: Purified or distilled water

Features and Advantages:

1. JPT Laser Source, Hanli Chiller, Thickened Sheet Metal Structure, Firm and Anti-deformation.

2. Non-contact 360° Cleaning. No Damage to the Base Material. No Consumables Cost Saving. Zero Emission, No Chemical Pollution.

3. Upgraded Laser Cleaning Head, Light and Easy to Use, Long-time Operation without Burning the Lens.

4. Red Light Assisted Positioning, Red Dot and Line Coincidence Focus, Precison Control, Easy Operation.

5. 7m Brand Optical Fiber Cable, Convenient for Long-distance Cleaning of Large Irregular Workpieces.

6. 1000mm/s Ultra-high-speed Intelligent Control Galvanometer System, Automatic Optimization of Acceleration and Deceleration Power.

7. Simple English Operation Interface. Common used Parameters can be Stored as Craft Files.

8. Fast Cleaning Speed,  400mm Focal Length, Cleaning Width up to 160±10mm.

9. Suitable for Large-scale Efficient Cleaning of Paint, Rust, Oil Stains, Oxide Layers, etc.

10. Offer Sample Test Service Before Purchasing. You can send samples to our US representative, or we can find similar material to make a test at our factory.

Application:

• Applicable Material: Stainless Steel, Carbon Steel, Aluminum, Copper, Galvanized Sheet, Iron, Steel, Nickel Plate, Manganese Plate
• Common Applications: Classic Car Rust Painting Repair, Steel Structure Rust Removal, Wall Graffiti Removal, Metal Parts Cleaning, Derusting parts, Gear Decontamination, Casting Paint Removal, Mold degreasing, Weld Seam Cleaning, Paint Stripping and Removal, Rust and Corrosion Removal, etc.
• Mill scale of hot-rolled steel, light-colored paint and high-temperature-treated paint or coating are not easy to remove. Please confirm with us before placing an order. It would be better to send samples for testing.

Service and Delivery:

1) 1 Year Warranty for the Whole Machine, 2 Years Warranty for the Laser Source. (Consumables are not covered by warranty)

2) After Sales Center in NY, US. Offer Remote Assistance for Operation Issues, Lifetime Online Technical Support.

3) Free Shipping by Fedex/UPS about 7-15 days to Your Door, No Import Duty for American Customers.

4) Consumables are Protective Lens, You can Buy more together with the Machine.

5) We also have Mobile Laser Cleaner for Optional

6) More cleaning cases, please visit our Youtube Channel SFX Laser

7) Recommended Match: Smoke Purifier.The Smoke Purifier can filter and purify the smoke, soot, dust, etc generated from the laser cleaning processing. Protect the operator from the harmful gas. (Package Purchase Save $150)
