Desktop 20W/30W/60W/80W/100W JPT MOPA M7(YDFLP-E-M7-M-R) Fiber Laser Engraver Laser Marking Machine
Application Advantage: Metal surface processing, peeling coating; Anodized Aluminum black marking; Semi-conductor&electronics industry applications; Large area engraving; Excellent marking effect on plastic or other sensitive material; Black and color marking on stainless steel.
- Product Code:SFX-GD-ME-B
- Availability: In Stock
- Product Size:710 x 750 x 1400 mm
|Packing Size:||870(L) x 790(W) x 1130(H) mm|
|G.W / N.W:||135 / 110 kg|
In Stock 20
- Laser Source: 20W/30W/60W/80W/100W YDFLP-E-M7-M-R JPT MOPA M7
- Adjustable Frequency Range: 1-4000kHz
- Marking Area(Lens): 110*110mm/150*150mm/175*175mm Optional
- Rotary Axis: D80/100/125mm Optional
- Adjustable Pulse Width Range : 2-350ns(20W/30W); 2-500ns(60W/80W/100W)
- Maximum Pulse Energy: 0.8mj(20W/30W); 1.5mj(60W/80W/100W)
- Software: EZCAD2(compatible with lightburn)/EZCAD3. Support WIN7/8/10 System
- Imported laser scanning system makes the marking speed up to 7m/s; Re-position precision is 0.002mm; High-Rate of Electrical-Optical Conversion: up to 70%.
- 2 Years Warranty. Offer customer and technical support. Easy Operation, English User Manual, VCD training video, software sending together with the machine
- The function of marking software is powerful. The machine can be compatible with software files such as Coredraw, AutoCAD, Photoshop;PLT,PCX,DXF,BMP,etc supported.
- The machine can directly use SHX, TTF fonts;Automatic encoding, printing serial number, batch number, date, barcode, QR code, automatic jump number, etc supported.
- Applicable Material: Aluminum, Stainless Steel, Brass, Copper, etc. Also some of nonmetal such as nylon, light button, ABS, PVC, PES, etc.
- Applicable Industry: Hardware industry, wrenches, measuring tools, sanitary ware, stainless steel, medical equipment, luggage, gifts, table bottom, glasses frames, instruments.
- Application Advantage: Metal surface processing, peeling coating; Anodized Aluminum black marking; Semi-conductor&electronics industry applications; Large area engraving; Excellent marking effect on plastic or other sensitive material; Black marking on stainless steel.
- Free Shipping by Air to Door inlcuding Tariffs and Broke Fees around 15 to 25 days. No Import Duty for American Customers.
- After Sales Center in NY, US. Offer Remote Assistance for Operation Issues. Lifetime Online Technical Support. CE, ISO & FDA Certificate.
|Laser Source||JPT MOPA M7|
|Adjustable Frequency Range||1-4000kHz|
|Adjustable Pulse Width Range||2-350ns|
|Min. Line Width||≤0.01mm|
|Output power adjustment range||10%-100%|
|Communication Mode for Automation||TCP/IP, IO,RS232|
