1000W/1500W/2000W/3000W Mobile Laser Cleaning Machine Integrated Water-cooler CW Fiber Laser Cleaner
SFX Mobile Fiber Laser Cleaner Metal Rust Remover. Easily Remove Rust, Painting, Oil, Coating without Damage to Substrate. Continuous Operation without Burning the Lens. Integrated Water-Cooler Chassis. 5-10 days to your door by Air.
- Product Code:BLC-1000/1500/2000/3000
- Availability: In Stock
- Weight:106 kg
|Packing Size:||1.12(L) x 0.56(W) x 1.05(H) m|
In Stock 40
- Laser Source Power: MAX 1000W/1500W/2000W/3000W
- Laser Wavelength: 1080±10nm
- Scanning Width: 160±10mm
- Laser Type: Continuous
- Maximum Modulation Frequency: 20KHz
- Output Power: 6KW/8KW/10KW/13KW
- Cleaning Efficiency: 15-45m2/h
- Cable Length: 10m (1000W/1500W/2000W,15m customizable); 20m(3000W)
- Voltage:220V 1-Phase(1000W/1500W/2000W); 380V 3-Phase(3000W, Transformer included)
- Cooling Method: Water Cooling (Medium; Deionized Water, Distilled Water or Purified Water)
- Package Dimensions: 1120*565*1050mm/1430*720*1220mm
- Water Tank Capacity: 16L (14-15L of Water to be Added)
Features and Advantages:
- MAX Laser Source, Hanli Chiller, Thickened Sheet Metal Structure, Firm and Anti-deformation. Excellent Quality Products Materials from First-line Manufacturers.
- Upgraded Laser Cleaning Head, Independent Research and Development, Continuous Operation without Burning the Lens. Lightweight and Easy to Use.
- Where the Laser Goes, All can be Cleaned. Non-contact 360° Cleaning, Not Limit by Space and Location, Environmentally Friendly without Consumables.
- Red Light Assisted Positioning, Precise Control, Easy Operation. Double-click the Switch to Start Cleaning, Avoiding Accidental Touch and Operation is Safer.
- 550-600mm Focal Length, Cleaning Width up to 160±10mm. High Tolerance, Low Light Attenuation. Flexible and Easy to Clean on Large Irregular Workpieces.
- Integrated Water-cooler Chassis. Small Volume(0.23m³/0.28m³/0.83m³), Easy to Put in a Car for Outdoor Cleaning.
- Ergonomic Design. Easy to Push. Passed Many Rigorous Tests in the Industry such as Continuous Working Test, High Contamination Test, etc.
- Easy Operation, English User Manual, Training and Operation Video Sending Together with the Machine.
- 3000W Efficiency is about 3.8 times of 1500W, 2.7 times of 2000W
- Compared with Pulse Type Laser Cleaning Machine, Continuous Fiber Laser Cleaner is More Suitable for Applications Where High Efficiency is Required.
- Applicable Industries: Aviation and Marine, Electromechanical, Rubber Mold, Equipment Manufacturing, Auto Parts, Food Processing.
- Common Applications: Classic Car Rust Paint Repair, Steel Construction Rust Removal, Graffiti Removal, Metal Parts Cleaning, Derusting Parts, Gear Decontamination, Casting Paint Removal, Mold Cleaning, Weld Seam Cleaning, Paint Stripping and Removal, Rust and Corrosion Removal, etc
- Mill scale of hot-rolled steel, light-colored paint and high-temperature-treated paint or coating are not easy to remove. Please confirm with us before placing an order. It would be better to send samples for testing.
Service and Delivery:
- 1 Year Warranty for the Whole Machine, 2 Years Warranty for the Laser Source. (Consumables are not covered by warranty)
- After Sales Center in NY, US. Offer Remote Assistance for Operation Issues, Lifetime Online Technical Support.
- Free Shipping to Your Door by Air (DHL/UPS/Fedex) about 5-10 Days, No Import Duty for American Customers.
- Consumables are Protective Lens,You can Buy More Together with the Machine.
- Recommended Match: Smoke Purifier.The Smoke Purifier can filter and purify the smoke, soot, dust, etc generated from the laser cleaning processing. Protect the operator from the harmful gas. (Package Purchase Save $150)
- SFX Laser Cleaning Machine Customers Feedback
We also have 1 set Used BLC-2000 Laser Cleaning Machine in Canada with 10m cable length, Price $11082.
1 set Used BLC-3000 Laser Cleaning Machine in America with 20m cable length, Price $16330.
If interest, please contact us at [email protected]
|Cable Length||10m (15m can be Customized)|
|Cooling Method||Water cooling|
|Laser Source Power||1000W/1500W/2000W/3000W|
|Maximum Modulation Frequency||20KHz|
|Voltage||220V 1-phase(1000W/1500W/2000W); 380V 3-phase(3000W)|
|Water Tank Capacity||16L (14-15L of Water to be Added)|
